Water Gate Opening Indicator

Water gate indicator is important equipment for control of water gate on dam and river weir etc.
We have a lineup of indicators and converters which are suitable for purpose and site condition.

Water Resistant Shaft-Rotation Type (GIN200 Series)

GIN200 Series is a gate opening indicator by directly  measuring a shaft rotation of the water gate hoist.
Also available for submersible Derricking gate because of water-resistant structure (up to 10m depth)
Synchro transmitter can be mounted for output signal.

Features

• ・Direct input of shaft rotation of gate hoist
• ・Water-resistant stuctuer (up to 10m depth)
• ・Available synchro transmitter (type 86G)
• ・Selectable reduction gear ratio(6/1~1/10)

Available sites

• 　・Water gate


Main specification

Ambient Temperature	-10 to +50ºC (Non fleezing)
Water Resistant Depth	Max.10m
Allowable rotation speed	10r/min.
Allowable radial load	49N(15kg･f)
Allowable thrust load	29.4N(3kg･f)
Shaft friction torque	1.47N･m(15kg･f-cm)
Gear ratio	Selectable 6/1 to 1/10 (2-step gear)
Weight	Approx. 20kg

Gear ratio

GR.No	Gear ratio	GR.No	Gear ratio	GR.No	Gear ratio
01	1/1	12	6/1	26	9/10
02	1/1.25	13	5/1	27	1/3
03	1/1.44	14	4.5/1	28	1/2
04	1/1.5	15	4/1	29	1/2.5
05	1/2.8	16	3.6/1	30	1/3.6
06	1/3.2	17	3/1
07	1/3.8	18	2/1
08	1/4	19	1.6/1
09	1/5	20	1.5/1
10	1/10

Option

Model name: GIN210-86S[X]

Code	Option Type	Option Number	Output Signal Cable	Position of Conduit -connection
[X]	Cable Connection	A	Pre-connected	A (right side in front)
		B	Pre-connected	B (left side in front)
		C	None	A (right side in front)
		D	None	B (left side in front)
